Description:
Resolution: 1280*960
Resolution: 600TVL
Camera size: 12.5mm * 12.5mm * 17mm
Lighting: 0.5LUX
System: NTSC
Power range: 3.7-5V100 mAh
Audio lens: 1.8 mm wide angle (170 degrees)
Image sensor: 1/4 CMOS image sensor
Photosensitive area: 3.5964 mm x2.7084 mm
648 pixels (horizontal) × 488 (vertical) 648 (horizontal) × 488 (vertical)
Scanning frequency level: 15.625KHz
Vertical: 50 Hz
Rating: 15.733KHz
Vertical: 60 Hz
1/60-1/80000 (seconds) of the electronic shutter 1/50-1/80000 (seconds)
Signal to noise ratio ≥48dB (AGC OFF)
Minimum illumination: 0.1 lux / F1.2
Composite video signal: 1.0VP-P75Ω
Standard lens: 1.8 mm
PCB specification: 20mm * 20mm
Power: DC5V70 mA ± 10% ± 10%
Operating temperature: -10 ° C ~ 60 ° CRH 95% maximum
Package included:
1 x 600TVL Wide-angle Camera Lens
