Description:
Easy to connect wire and use, knob operation.
In response to the output immediately after adjustment, no delay.
Adjust the actual fineness of up to 0.01mA, operate freely.
With polarity protection, power reverse does not work, do not burn components.
Power supply voltage: 12V DC or 24V (tolerance ± 25%), Total power <1W.
Output load impedance range between 0-350 ohms(DC 12V); 0-800 ohms(DC 24V).
Can be used: signal sources, regulating valves, test instrumentation, light emitting diode test, the inverter output analog transmitter.
Specifications:
Power Supply: DC 12V/24V
Total Power: <1W
Output: 4-20mA
Output Load Impedance: 0-350 ohms(DC 12V); 0-800 ohms(DC 24V)
Overall Size: 80mm * 42mm
Weight: 55g / 1.94oz
Package Size: Approx. 12 * 7 * 4cm
Package Weight: 61g / 2.16oz
Package Included:
1 x 4-20mA Signal Generator DC 12V 24V PWM Frequency Pulse Function Generator Adjustable Constant Current Anti Reverse for LED Light
