Features:
Weight:28 g
Size:67.5mmx41.5mmx14mm/2.66"x1.63"x0.55"(inch) (approx).
Performance parameters:
1.Input Voltage:3-35V DC (Note: When input voltage is less than 4V, onboard voltmeter will not work).
2.Input Current:9A (max).
3.Output Voltage:3.5-35V DC (this board is boosting board, output voltage>=Input voltage).
4.Output Current:6A (max).
5.Output Power: 65W (when the input and output voltage greater than 20V up to 100W).
6.Conversion Efficiency: 96% (the highest).
7.Output Ripple:40mV(TYP).
8.Onboard Voltmeter Range:4-40V .
9.Error:+/-0.1V.
Package Included:
Weight:28 g
Size:67.5mmx41.5mmx14mm/2.66"x1.63"x0.55"(inch) (approx).
Performance parameters:
1.Input Voltage:3-35V DC (Note: When input voltage is less than 4V, onboard voltmeter will not work).
2.Input Current:9A (max).
3.Output Voltage:3.5-35V DC (this board is boosting board, output voltage>=Input voltage).
4.Output Current:6A (max).
5.Output Power: 65W (when the input and output voltage greater than 20V up to 100W).
6.Conversion Efficiency: 96% (the highest).
7.Output Ripple:40mV(TYP).
8.Onboard Voltmeter Range:4-40V .
9.Error:+/-0.1V.
Package Included:
1PCS * DC 3-35V To 3.5-35V 100W LED Voltmeter Step-up Power Supply Boost Module
